A20B-2902 Series — FANUC's Module Board Family

The A20B-2902 series encompasses a wide range of plug-in module boards that expand or enable specific functions within FANUC CNC controllers. These boards serve multiple roles across the FANUC product range:

Memory expansion modules: FROM (Flash ROM), SRAM, and DRAM boards that add programme storage, parameter retention, and working memory capacity to the main CPU board.

Servo and spindle control modules: Daughter boards that add servo axis control logic or analogue spindle interface capability to the main control board.

PMC (Programmable Machine Control) modules: Boards that expand the PMC's programme memory, data registers, or instruction capability.

Function-specific interface modules: Boards providing serial communications, specialised I/O interfaces, or other optional CNC functions.

The A20B-2902-0671 is one board in this extensive family, manufactured to FANUC's Japan production standards and designed for plug-in installation in compatible FANUC CNC or automation control systems.

Key Product Information

Plug-In Installation — Minimal Disruption to System Configuration

Boards in the A20B-2902 series are designed as plug-in modules. They connect to the main CPU board or motherboard via edge connectors or socket connections — no soldering, no modification to the host board. A replacement A20B-2902-0671 installs and removes from its slot without disturbing adjacent modules or the host board's wiring.

This plug-in architecture is deliberate: FANUC designed it to enable field-level module replacement without requiring PCB soldering skills or specialised repair equipment. A maintenance technician with the correct ESD precautions and knowledge of the system's module locations can fit the replacement board.

Application Scenarios

System maintenance: A FANUC CNC system develops a module-level fault traced to the A20B-2902-0671 board. The replacement board is plugged in after removing the failed module. The system resumes normal operation with the board's function restored.

Spare parts management: A production facility running multiple FANUC CNC systems maintains an A20B-2902-0671 as a local spare board. In the event of a module failure, the replacement is available immediately — avoiding an unplanned shutdown while awaiting shipping.

FAQ

Q1: How do I confirm the A20B-2902-0671 is the correct module for my FANUC system?

Read the part number directly from the label on the installed module. If it reads A20B-2902-0671, this board is the correct replacement. Cross-referencing can also be done through the CNC's spare parts list in the maintenance manual — the module's slot location and part number are listed for each optional and standard board in the system configuration.

Q2: Can A20B-2902 series modules from different part numbers be substituted for each other?

No. Each A20B-2902 part number represents a different functional module — different memory types, capacities, interface functions, or control configurations. Adjacent part numbers in the series are not interchangeable. Always use the exact part number matching the installed board.

Q3: Does replacing the A20B-2902-0671 require any system configuration changes?

This depends on the specific function of the board. Memory modules typically require no configuration changes — the system detects the module on power-up. Functional modules (servo, spindle, PMC interface) may require parameter verification or entry after replacement. Consult the FANUC maintenance manual for the specific CNC model and module type to determine the post-replacement procedure.

Q4: What are the ESD handling requirements for the A20B-2902-0671?

The A20B-2902-0671 is an SMD (Surface Mount Device) constructed PCB with CMOS memory or logic ICs that are sensitive to electrostatic discharge. Handle only with a grounded anti-static wrist strap on a grounded work surface. Transport and store in anti-static packaging. Never handle the board by touching circuit components or trace areas — hold by the PCB edges only.
