SANYO FAN 109P042H6D14 1O9PO42H6D14

109P042H6D14 | Sanyo Denki San Ace DC Axial Fan — 24V / 3-Wire / Ball Bearing / Industrial Automation and Control

Sanyo Denki San Ace — Industrial DC Fan for Automation Electronics

The 109P042H6D14 is a Sanyo Denki San Ace series DC axial fan for 24V industrial electronics cooling. Sanyo Denki's San Ace fan line is designed and manufactured to the reliability standards required in continuous-duty industrial applications — PLC cabinets, servo drive enclosures, CNC machine tool control electronics, and industrial automation equipment.

The 3-wire connection provides both the 24V DC power supply and a tachometer/alarm signal output — enabling the host system to monitor fan operation and generate fault alerts on fan failure. This monitoring capability is a standard feature in Sanyo Denki's industrial fan range, making their products compatible with the fan fault monitoring circuits found in professional industrial control equipment.

Key Product Information

3-Wire Interface — Monitoring and Power

The 3-wire configuration is the industrial standard for monitored cooling fans:

Power wires: Two wires carry the 24V DC positive and negative supply — the motor's power.

Signal wire: The third wire carries the fan's tachometer or alarm signal — a pulsed output proportional to fan speed that the host system reads to confirm the fan is operating.

Alarm detection: When the tachometer signal drops to zero (fan stopped), the host equipment generates a fan fault alarm. In industrial PLCs and drives, this alarm may trigger a warning, a controlled shutdown, or a service request depending on the specific system configuration.

Applications

Automation controller cooling: Industrial PLC enclosures, safety controller modules, and automation computer electronics — the 24V San Ace fan integrates directly with the controller's 24V supply rail.

Servo and motion control equipment: Servo drive module cooling, motion controller electronics, and axis control card thermal management in CNC machine tools and industrial robots.

Drive and inverter enclosures: Internal cooling fan positions in variable frequency drives and servo amplifiers where compact 40mm fan mounting positions require reliable 24V DC cooling.

Industrial computing: Industrial panel PCs, embedded controllers, and edge computing hardware requiring continuous-duty 24V fan cooling in controlled environments.

FAQ

Q1: How does 109P042H6D14 relate to the 109P0424H6D14 in the San Ace product range?

Both part numbers share the San Ace 109P series designation and the H6D14 performance suffix — the 0424 segment in 109P0424H6D14 explicitly identifies the 40mm size and 24V supply voltage. The 109P042H6D14 is the same series and class fan; confirm exact specifications from the Sanyo Denki product documentation for the specific part number to verify dimensions and performance data for the installation.

Q2: What failure modes should I watch for with the 109P042H6D14 in industrial service?

Ball bearing fans typically fail from bearing lubricant depletion — onset is gradual: increasing bearing noise (grinding or squealing), intermittent speed reduction, then complete stall. The 3-wire tachometer output enables early detection of speed reduction before complete failure. In clean environments, fans generally reach their rated life; in dusty or oil-contaminated environments, accelerated contamination of the bearing seal shortens service life significantly.

Q3: Can the 3-wire signal output from 109P042H6D14 be used for both speed display and alarm triggering?

Yes — the tachometer output generates a pulse train at a frequency proportional to RPM. This signal can feed simultaneously into a frequency counter for RPM display and a minimum-frequency comparator circuit for alarm triggering. Many industrial PLCs and drive controllers provide dedicated fan tachometer inputs that process both functions from the single third wire without external circuitry.

Q4: What is the correct orientation for mounting 109P042H6D14?

Ball bearing fans operate reliably in any mounting orientation — horizontal shaft (fan blowing horizontally), vertical shaft upward (fan on bottom of enclosure), or vertical shaft downward (fan on top of enclosure). Unlike sleeve bearing fans that require specific orientations for lubricant distribution, the 109P042H6D14's ball bearings maintain consistent lubrication regardless of mounting angle. Mount with the fan label face pointing in the intake direction to confirm the correct airflow direction.
