Fanuc PC Circuit Board A16B-2200-0220 A16B-22OO-O22O A16B22000220

FANUC A16B-2200-0220 3/4 Axis PCB for 0-C Control

If the control system is built around early 16-bit FANUC 0-C architecture, the axis board has to match the original motion structure closely. The A16B-2200-0220 is a 3/4-axis 16-bit axis control PCB for FANUC 0-C systems.

It is described as a plug-in peripheral board that fits the 0-C master board, provides 3 or 4 channels of 16-bit servo control, and is used with A20B-1002-0360 or A20B-1003-0750 master boards. It is also tied to A06B-6057 and A06B-6058 servo drive families.

This board belongs to the motion-control layer, not to the graphics, I/O, or memory section.

In practical use, it is the board responsible for managing 3 or 4 axes inside the 0-C control platform, which makes it a precise replacement part for installed legacy 16-bit systems that still rely on this original servo-control arrangement.

Technical Data

Application Scenarios

A16B-2200-0220 is used in FANUC 0-C machining and turning controls where the installed system requires 3-axis or 4-axis digital servo control on a 16-bit platform.

It is suitable for axis-board replacement, 0-C control restoration, and service work on machines that still use the original 0-C master and digital servo amplifier arrangement.

Product Advantages

A major advantage of this board is that its application scope is very clear: 0-C, 16-bit, 3/4-axis control.

That makes it easier to match accurately in legacy controls.

Another advantage is that it is directly associated with known master boards and servo amplifier families, which helps narrow selection and reduces the risk of confusing it with other 0-series axis cards.

FAQ

Q1. What type of board is A16B-2200-0220?
It is a 16-bit 3/4-axis axis control PCB for FANUC 0-C systems. It plugs into the 0-C master board and provides multi-axis servo control.

Q2. What does this board do in the system?
Its role is to control 3 or 4 servo axes inside the 0-C control structure. It belongs to the motion-control section and works with the system’s digital servo drive arrangement.

Q3. What should be checked when selecting A16B-2200-0220?
Check the exact part number, confirm the machine uses FANUC 0-C 16-bit control, verify whether the application is 3-axis or 4-axis, and confirm the installed master board and servo drive family. The known master board references are A20B-1002-0360 and A20B-1003-0750, and the board is linked to A06B-6057 / A06B-6058 drive families.

Q4. How should the key specification be understood?
“3/4 axis” defines the axis-control scope, and “16-bit 0-C” defines the control generation and platform. These are not minor details; they are the main identifiers for proper matching.

Q5. How should faults be diagnosed before replacing this board?
A practical diagnosis starts by separating an axis-board fault from a servo amplifier fault or a master-board issue. If the machine is a 0-C system and axis-control problems are limited to the channels managed by this board, while the rest of the control remains stable, the 3/4-axis PCB becomes a stronger replacement candidate.
