The Siemens SIMOVERT MASTERDRIVES (6SE70 series) is a family of modular AC drive systems designed for industrial variable-speed motor control. MASTERDRIVES covers both Vector Control (VC) — for precise speed and torque regulation of standard AC induction motors — and Motion Control (MC) — for servo-level position and speed control of synchronous servo motors.
The modular architecture of the SIMOVERT MASTERDRIVES system is its defining engineering characteristic:
Separate control and power sections: The MASTERDRIVES system separates the control electronics (the technology unit or CU — Control Unit) from the power electronics (the PEU — Power Electronics Unit). This separation means faults in either section can be diagnosed and rectified independently — replacing the PEU without touching the control unit, or replacing the control unit without disturbing the power hardware.
Scalable power range: The 6SE70 series spans a wide power range — from compact low-power units to large multi-axis drive systems — using common control unit software and hardware across the range while scaling the PEU for each power class.
| Parameter | Value |
|---|---|
| Series | SIMOVERT MASTERDRIVES (6SE70xx) |
| Output Current | 34A |
| Input | 3-phase |
| Input Voltage | 380–460V AC |
| Module Type | PEU (Power Electronics Unit) — Spare Part |
| Function | Power controller module for MASTERDRIVES units |
The 34A output current rating at 380–460V AC positions 6SE7023-4EC84-1HF3 in the 15kW class of the SIMOVERT MASTERDRIVES range — confirmed by the 6SE7023-4EP60 adjacent variant's confirmed rating of 34A / 15kW at 380–480V AC.
At 34A continuous and 380–460V AC input, this PEU module serves the standard industrial motor power class that covers:
MASTERDRIVES power stage fault: A Siemens SIMOVERT MASTERDRIVES drive in the 34A class develops power stage faults — IGBT overcurrent, DC bus faults, or gate drive failures. The control unit is verified as healthy. The 6SE7023-4EC84-1HF3 PEU module is identified as the fault. Replacement of the power electronics module restores drive function without requiring replacement of the control electronics.
Planned power module maintenance: A facility using SIMOVERT MASTERDRIVES systems in continuous production replaces the 6SE7023-4EC84-1HF3 PEU as part of a scheduled power electronics maintenance interval — proactively renewing the IGBT modules before in-service failure occurs.
Q1: What is the difference between the PEU (Power Electronics Unit) and the control unit in the SIMOVERT MASTERDRIVES system?
The MASTERDRIVES system separates into two main hardware layers. The PEU (6SE7023-4EC84-1HF3) contains the rectifier, DC bus, IGBT inverter, and gate drive circuits — the power hardware that actually converts electrical energy to drive the motor. The control unit (CU) contains the microprocessor, speed and torque control algorithms, fieldbus communications, and the operator interface. Fault diagnosis determines which layer has failed. PEU faults cause power-stage alarms; CU faults cause software or communications alarms.
Q2: How do I diagnose whether the fault is in the 6SE7023-4EC84-1HF3 PEU versus the control unit?
SIMOVERT MASTERDRIVES displays fault codes on the operator panel (OP1S) or parameterisation unit. PEU-specific faults typically appear as: F001 (overcurrent), F002 (overvoltage), F006 (IGBT short circuit), F026 (gate unit fault), or similar power electronics codes. These indicate the power stage rather than the control logic. Control unit faults produce different fault codes related to software, communication, or sensor failures. Always record the fault code before removing any hardware.
Q3: What input supply quality does 6SE7023-4EC84-1HF3 require?
The 6SE7023-4EC84-1HF3 requires a balanced 3-phase supply within the 380–460V AC range. Supply quality requirements include: phase-to-phase voltage balance within approximately 3% of nominal, total harmonic distortion (THD) below the limits defined in the applicable Siemens MASTERDRIVES installation guidelines, and adequate short-circuit current available at the drive connection point. Install appropriate input line reactors or EMC filters as specified in the MASTERDRIVES installation documentation for the specific application.
Q4: What safety precautions apply when replacing 6SE7023-4EC84-1HF3?
Isolate and lock out the 3-phase mains supply to the MASTERDRIVES unit. The DC bus capacitors retain charge at potentially lethal voltage (500V+ DC) after mains isolation — wait the full discharge time specified in the MASTERDRIVES maintenance manual (typically several minutes) and verify DC bus voltage is below 50V using a calibrated instrument before accessing internal components. Handle the 6SE7023-4EC84-1HF3 PEU with care — the IGBT modules inside are electrostatic-sensitive. Use anti-static precautions when handling the replacement module.
Q5: After fitting a replacement 6SE7023-4EC84-1HF3, does the drive need parameter reconfiguration?
Drive parameters reside in the control unit — not in the PEU hardware module. Replacing the 6SE7023-4EC84-1HF3 does not change the drive's parameter set. After fitting the replacement module, restore the mains supply and verify the drive completes its power-on self-test without fault codes before enabling the motor. Confirm correct motor current readings at low speed before returning the drive to full production load.
