6SE7090-0XX84-1GA1 | Siemens SIMOVERT MASTERDRIVES VSB Voltage Sensing Board — Three-Phase AC Measurement / AFE Drive Supply Monitoring

Measuring the Grid — What the VSB Does

The 6SE7090-0XX84-1GA1 VSB (Voltage Sensing Board) continuously measures the three-phase AC supply voltage at the MASTERDRIVES drive's mains input. This measurement is not incidental — for AFE (Active Front End) drives, it is operationally essential.

An AFE inverter at the drive's input operates by actively switching in synchrony with the supply voltage. To switch in synchrony, it must know the supply voltage at every instant:

• The exact phase angle of each supply phase
• The instantaneous voltage amplitude on each phase
• The supply frequency, updated cycle by cycle

The VSB delivers all three parameters as real-time analog signals to the CUSA (AFE control module), which uses them continuously for its switching calculations. Remove or disable the VSB, and the AFE cannot synchronise — it becomes a standard diode rectifier at best, or generates a synchronisation fault at power-up.

Key Specifications

Three-Phase Measurement Architecture

The VSB measures all three phases of the AC supply — not just one or two. Three-phase measurement is necessary because:

Phase balance monitoring: Industrial supplies are not perfectly balanced. A 5% imbalance between phases affects the AFE's ability to draw equal current from each phase. The VSB's three-phase measurement allows the CUSA to detect imbalance and compensate in its switching pattern.

Phase loss detection: Loss of one supply phase produces a different voltage signature than a supply undervoltage. Three-phase measurement allows the VSB to distinguish between these conditions — enabling appropriate protective responses (phase loss shutdown versus low-voltage alarm).

Zero-crossing detection: The AFE's synchronisation algorithm uses the zero crossings of each supply phase to track the supply frequency and phase angle. Three-phase zero crossing data provides three independent phase-locked loop references — improving synchronisation accuracy and speed.

Application Scenarios

AFE synchronisation failure — VSB fault: A MASTERDRIVES AFE infeed unit fails to synchronise with the supply at power-up — generating a synchronisation alarm before the DC bus reaches operating voltage. Supply quality is verified as acceptable with external instruments. The 6SE7090-0XX84-1GA1 VSB is identified as providing degraded or missing voltage signals to the CUSA. Replacement restores AFE synchronisation.

Supply phase monitoring failure: An AFE infeed unit loses the ability to detect supply phase imbalance — a maintenance alarm indicates the phase monitoring function is inactive. The VSB is identified as the measurement source for this function.

FAQ

Q1: How does the VSB physically connect to the AC supply for its measurements?

The VSB connects to the drive's mains input terminals through voltage divider or transformer-coupled measurement circuits — not by carrying the full supply current. The voltage sensing circuits bring a scaled-down representation of each phase voltage to the VSB's signal-level electronics, where analog processing produces the measurement data that feeds the CUSA. The VSB wiring is low-power sensing circuitry, not a power-carrying connection.

Q2: What alarms indicate a 6SE7090-0XX84-1GA1 VSB fault versus a supply problem?

A supply problem (actual voltage loss, phase imbalance) produces consistent alarms correlated with measured external supply conditions — confirmed by external voltage measurement. A VSB fault may produce: phase measurement alarms when the supply is verified as healthy by an external instrument, intermittent synchronisation failures despite stable supply, or incorrect power factor readings. If external voltage measurement confirms supply quality but the MASTERDRIVES continues to report supply faults, the VSB is the likely cause.

Q3: Can the AFE unit operate without the 6SE7090-0XX84-1GA1 VSB installed?

No — the AFE unit cannot operate in active rectification mode without the VSB. The CUSA requires continuous three-phase voltage measurement for its switching synchronisation algorithm. Without valid VSB measurements, the CUSA generates a startup fault and prevents AFE operation. The drive may continue to operate in a degraded mode through a passive rectifier path (if one is fitted) but active power factor control and regenerative capability are unavailable.

Q4: Does replacing 6SE7090-0XX84-1GA1 require AFE recalibration?

No specific calibration is required after replacing the VSB. The module's voltage sensing circuitry has fixed, consistent scaling — it does not require user calibration. After fitting the replacement VSB, the CUSA reads the restored voltage measurements and the AFE should complete synchronisation normally. Verify AFE synchronisation and correct power factor display on the drive's operator panel before returning to full production.

Q5: What safety precautions apply when replacing the VSB?

Isolate and lock out the mains supply to the AFE unit. The VSB connects to the mains input terminals — these carry line voltage even when the AFE inverter is not switching. After mains isolation, verify the DC bus has discharged below 50V before opening the drive enclosure. The VSB's measurement wiring connects to the mains terminals — confirm these are de-energised before handling the VSB connections. Handle the replacement module with anti-static precautions.
