6SE7090-0XX84-0AD1 | Siemens SIMOVERT MASTERDRIVES Motion Control CU — 60MHz Control Unit / Universal Spare / Servo Drive Applications

From Speed Control to Motion Control — The CU's Role

The 6SE7090-0XX84-0AD1 is the Control Unit (CU) for SIMOVERT MASTERDRIVES Motion Control systems. This module is the drive's intelligence — executing all the closed-loop control algorithms that translate speed, position, or torque setpoints into PWM commands to the gate drivers and IGBT inverter.

In the MASTERDRIVES architecture, every drive unit contains a CU. What makes the 6SE7090-0XX84-0AD1 distinct is its Motion Control software — the set of algorithms built into the 60MHz processor that extend the drive's capability from simple speed regulation to full motion control:

Speed and torque regulation: The fundamental closed-loop algorithms present in all MASTERDRIVES CU variants — proportional-integral velocity loops and fast inner current loops.

Position control: The Motion Control CU adds a position control outer loop — accepting position setpoints and managing the velocity profile to achieve precise positioning. This is not available in Vector Control CU variants.

Coordinated motion: Multiple 6SE7090-0XX84-0AD1 Motion Control drives can be synchronised to perform coordinated multi-axis motion — essential for applications like gantry systems, coordinated winders, and electronic gearboxes.

Key Specifications

Applications Where Motion Control CU Is Required

The 6SE7090-0XX84-0AD1 is the appropriate CU for MASTERDRIVES applications requiring any of:

Absolute position control: Any application where the drive must move a load to a precisely commanded position — and hold that position — needs the Motion Control CU. A Vector Control CU can only regulate speed; it cannot execute position control.

Synchronised axes: Applications where two or more drive axes must maintain a defined speed or position ratio — flying shears, cross-cutters, register control in printing machines, and electronic line-shafting in multi-motor drives.

Servo motor drives: The Motion Control CU supports synchronous servo motors (permanent magnet type) in addition to standard induction motors — providing field-oriented control for servo motor applications.

Application Scenarios

MASTERDRIVES Motion Control CU fault: A SIMOVERT MASTERDRIVES MC drive loses motion control function — the drive can still run in basic speed mode but position control and coordinated motion are unavailable. Diagnostic investigation identifies the 6SE7090-0XX84-0AD1 CU as the fault. Replacement with a correctly configured module restores full motion control capability.

MASTERDRIVES upgrade to Motion Control: A facility upgrades an existing MASTERDRIVES Vector Control drive to Motion Control capability. Replacing the Vector Control CU with 6SE7090-0XX84-0AD1 enables position control and synchronisation features — provided the drive also has the required encoder feedback module (SBP, SBM2, or SBR2) installed.

FAQ

Q1: What encoder feedback module is required alongside 6SE7090-0XX84-0AD1 for closed-loop position control?

The Motion Control CU (6SE7090-0XX84-0AD1) requires an encoder feedback signal for speed and position measurement. The appropriate sensor board depends on the encoder type: SBP (6SE7090-0XX84-0FA0) for incremental pulse encoders; SBM2 (6SE7090-0XX84-0FE0) for absolute multiturn encoders; SBR2 for resolvers. Without an encoder feedback module, the Motion Control CU cannot close the speed or position loops.

Q2: Does the 6SE7090-0XX84-0AD1 contain the drive's parameter set?

Yes. The CU module stores the drive's application-specific parameters — motor data, speed limits, ramp rates, encoder scaling, position loop gains, and control configuration. When replacing the CU, all parameters must be restored from a current backup. A replacement CU arrives with factory default settings — the application parameters must be loaded before the drive can operate correctly. Always maintain a current parameter backup before CU replacement.

Q3: Can 6SE7090-0XX84-0AD1 replace a Vector Control CU in the same drive unit?

Physically, both CU variants fit the same slot in the MASTERDRIVES electronics housing. Functionally, replacing a Vector Control CU with 6SE7090-0XX84-0AD1 enables Motion Control features — provided the rest of the drive (encoder feedback module, communications module) is configured to support Motion Control operation. This can be done as a deliberate upgrade, but requires proper commissioning of the Motion Control parameters. Consult the SIMOVERT MASTERDRIVES Motion Control configuration documentation before proceeding.

Q4: What communications interfaces does 6SE7090-0XX84-0AD1 support for motion control setpoint input?

The MASTERDRIVES Motion Control CU accepts setpoints through its internal process data channel — via installed communications modules (PROFIBUS CBP2, DeviceNet, or other fieldbus options installed in the additional CU slots). For standalone operation, analogue setpoint inputs on the drive's terminal block are also available. In coordinated multi-axis applications, the SIMOLINK (SLB) communications option enables high-speed synchronised setpoint transmission between multiple MASTERDRIVES Motion Control drives.
