Siemens A5E00130391 | A5E-Series Internal Drive PCB Assembly

Part Number: A5E00130391

Manufacturer: Siemens AG (Germany)

Product Type: Internal Drive Circuit Board — PCB Assembly

Product Family: Siemens A5E-Series Drive Components

Production Status: Discontinued

Overview

The A5E00130391 is a Siemens A5E-series internal circuit board for industrial drive and inverter systems. The A5E prefix is Siemens' internal component designation, applied across drive platforms from MICROMASTER through SIMOVERT MASTERDRIVES and SINAMICS. Each A5E number identifies a unique functional assembly — power supply, signal conditioning, gate driver interface, or measurement acquisition — within the drive's layered electronics architecture.

The A5E number on the installed board's label is the definitive reference for sourcing a replacement. Visual similarity alone is not a reliable guide — boards with different A5E numbers may look nearly identical but differ in circuit characteristics. A correct match on the A5E number is the only safe basis for a like-for-like replacement.

With the part discontinued, specialist industrial drive repair companies are the primary supply source, offering tested exchange stock and component-level repair services.

Key Specifications

FAQ

Q1: How is A5E00130391 confirmed as the correct replacement?

Check the A5E number printed on the installed board's label. Cross-reference against the drive's internal spare parts list. The label number is the only reliable reference — visual similarity between boards is not sufficient for confirmation.

Q2: Does the drive need reconfiguration after replacing this board?

A5E-series circuit boards do not store drive parameters. All configuration resides on the drive's main control board or memory card. After replacement, the drive reads its parameters normally — no re-commissioning required in most cases.

Q3: Where can a discontinued A5E00130391 be sourced?

Industrial drive repair and spare parts companies hold exchange stock for legacy A5E boards. Some also offer component-level repair of the original failed board. Request functional test documentation before purchase.

Q4: Can the board be tested before installation?

Bench testing requires the board's operating voltages and input signal conditions from the drive. Without these, only a visual inspection and static continuity check are possible. Full functional verification happens after installation in the drive.

Q5: What storage conditions apply to a spare A5E00130391?

Store in metallised anti-static packaging, in a dry environment between −25°C and +70°C. Label with the A5E number and removal date. Inspect for corrosion before installation if stored for more than two years.
