Fuji AR30F0R-11G Green 30mm Momentary Pushbutton
Operator Control
The Fuji Electric AR30F0R-11G provides manual input through a green, flush round button. Its spring-return mechanism restores the original position when released. One normally open and one normally closed contact support complementary control functions.
Technical Specifications
| Parameter |
Specification |
| Model |
AR30F0R-11G |
| Series |
AR30 |
| Product type |
Pushbutton switch |
| Button color |
Green |
| Head style |
Flush, round |
| Operating action |
Momentary, spring return |
| Contact arrangement |
1 NO + 1 NC |
| Mounting size |
30 mm |
| Illumination |
Non-illuminated |
| Operator protection |
IP65 with correct installation |
Panel Fit and Circuit Integration
The front-tightening mounting system secures the operator to the panel. Snap-on contact blocks simplify maintenance. The two contacts can serve separate circuit functions within their electrical ratings. Check the contact rating against the control voltage and load before wiring.
Application Areas
Suitable for operator stations on packaging machines, conveyors, machine tools, and automated assembly equipment. Typical uses include start commands, reset inputs, and jog control. The assigned function depends on the machine’s wiring and control logic.
FAQ
Q1: Does the button stay pressed?
A: No. It returns automatically when released.
Q2: What contact arrangement is included?
A: One normally open and one normally closed contact.
Q3: Is the green button illuminated?
A: No. This is a non-illuminated model.
Q4: What mounting size does it require?
A: A 30 mm panel mounting format.
