FANUC Pulse Coder Cable — The Encoder Feedback Link

The A660-2005-T506 is FANUC's pulse coder cable — the encoder feedback assembly connecting the FANUC servo amplifier's encoder input (CN2) to the pulse coder integrated in the FANUC servo motor. In FANUC's servo system terminology, the encoder built into the motor is called a "pulse coder" — a high-resolution absolute or incremental position sensor that provides shaft angle data to the servo amplifier for closed-loop velocity and position control.

The straight plug designation (T506) identifies this as the version with the connector body aligned with the cable axis. The alternative angled version (A660-2005-T505) has the cable exiting at 90° to the connector — both serve the same system function with different connector orientations for different mounting geometries.

Key Product Information

Pulse Coder — What the Cable Connects

Motor-side (pulse coder connector — black): The connector at the motor end mates with the FANUC servo motor's pulse coder socket on the motor body or end cap. FANUC uses the term "pulse coder" for the encoder assembly integrated into their servo motor family — the pulse coder provides high-resolution absolute position data (typically 1,000,000 counts/revolution for αi pulse coders) to the amplifier.

Amplifier-side (SVM connector — grey): The connector at the servo amplifier end mates with the FANUC Alpha iSVM module's CN2 (encoder feedback) socket. The grey amplifier-side connector identifies the A660-2005-T506 as the current series cable for the Alpha iSVM (Servo Motor Module) in the FANUC αi series drive system.

Signal content: The A660-2005-T506 carries the serial communication data of the FANUC αi pulse coder — a proprietary high-speed serial protocol transmitting absolute position, thermal data, and fault status from the motor encoder to the servo amplifier in real time.

Applications

FANUC CNC machine tool servo axes: FANUC α series and αi series servo systems on SINUMERIK-FANUC CNC machining centres, turning centres, and grinding machines — the A660-2005-T506 is the standard pulse coder feedback cable for Alpha iSVM-equipped drives.

FANUC industrial robots: FANUC robot models using Alpha iSVM servo modules for joint axis drives — the pulse coder cable connects each joint servo motor to its servo amplifier.

FANUC ROBODRILL and ROBODCUT: Compact machining centres and EDM machines using integrated FANUC servo systems — encoder cables for each controlled axis.

Multi-axis machining systems: 5-axis machining centres and multi-axis turning centres with FANUC servo drives across all axes — one A660-2005-T506 cable per servo axis.

FAQ

Q1: What is the difference between A660-2005-T506 (straight) and A660-2005-T505 (angled)?

Both carry identical signals and serve the same pulse coder interface — the difference is the connector body geometry. T506 exits the cable straight from the connector body; T505 exits at 90°. Select based on installation space at the motor's pulse coder socket — motors with restricted space behind the encoder connector often require the angled T505. In open mounting situations, either type is acceptable.

Q2: How does FANUC's pulse coder differ from a standard incremental encoder?

FANUC αi pulse coders use a high-speed proprietary serial communication protocol rather than the quadrature ABR signals of standard incremental encoders. The serial interface transmits absolute multi-turn position, temperature sensor data, and diagnostic information. This serial protocol requires the specific A660-2005-T506 cable — standard incremental encoder cables cannot substitute for FANUC pulse coder cables because the electrical interface (protocol, signal levels, connector pinout) is fundamentally different.

Q3: What FANUC alarm is generated when A660-2005-T506 fails or is disconnected?

FANUC generates Alarm SV401 (VRDY OFF) or SV436/SV437 (encoder cable error) when the pulse coder cable signal is lost or degraded. Alarm SV401 at axis enable indicates the servo amplifier has not received a valid pulse coder response — the first diagnostic check is the pulse coder cable connection at both ends. Intermittent cable faults typically produce position feedback errors or drifting alarms before complete cable failure.

Q4: Can A660-2005-T506 cable length be extended in the field?

FANUC pulse coder cables cannot be extended by field splicing — the proprietary high-speed serial protocol requires specific cable impedance characteristics that are disrupted by mid-cable connectors or splices. FANUC specifies maximum cable lengths for each pulse coder interface in their servo amplifier technical documentation. For installations requiring longer cable runs than available standard lengths, contact FANUC for the correct longer length variant.
