NEW HCMFS73K Mitsubishi Servo Motor HC-MFS73K Fast shipping
  • NEW HCMFS73K Mitsubishi Servo Motor HC-MFS73K Fast shipping
  • NEW HCMFS73K Mitsubishi Servo Motor HC-MFS73K Fast shipping
  • NEW HCMFS73K Mitsubishi Servo Motor HC-MFS73K Fast shipping
NEW HCMFS73K Mitsubishi Servo Motor HC-MFS73K Fast shipping

NEW HCMFS73K Mitsubishi Servo Motor HC-MFS73K Fast shipping

Place of Origin JAPAN
Brand Name MITSUBISHI
Certification CE ROHS
Model Number HC-MFS73K
Product Details
Condition:
New Factory Seal (NFS)
Item No.:
HC-MFS73K
Origin:
JAPAN
Weight:
3.6 KG
Dimension:
31 X 10 X 17 Cm
Highlight:

mitsubishi industrial servo motor

,

mitsubishi yaskawa ac servo motor

Payment & Shipping Terms
Minimum Order Quantity
1 pcs
Packaging Details
original packing
Delivery Time
0-3 days
Payment Terms
T/T, PayPal, Western Union
Supply Ability
100 pcs/day
Product Description

NEW HCMFS73K Mitsubishi Servo Motor HC-MFS73K Fast shipping 0



MITSUBISHI  NEW   HC-MFS73K  NEW Mitsubishi Servo Motor

lots of stock, best price offered

Description
   The Mitsubishi HC-MFS73K servo motor is a MELSERVO ultra low inertia and small capacity servo motor designed to meet the demands of a variety of industrial automation applications. It features a keyway shaft with a key. The HC-MFS73K servo motor has an output power rating of 0.75 kW. The motor operates at a rated torque value of 2.4 Nm and a rated speed of 3000 r/min. It is suitable for applications requiring precise control.



Parameter Specification
Primary brand Mitsubishi Electric
Main function AC servo motor
Product series / family name MELSERVO J2S series
Sub-range name HC-MF series
Functions AC brushless rotary servo motor
Design Keyed shaft, built-in absolute feedback encoder (17-bit), ultra-low inertia / small power capacity
Supply voltage (AC) 200Vac class
Rated current 5.1 A
Rated active power 750 W / 0.75 kW
Rotational speed 3000 rpm (4500 rpm maximum)
Torque 2.4 Nm nominal, 7.2 Nm maximum
Moment of inertia 0.00006 kg·m² (0.6 kg·cm²)
Mounting mode 80×80 mm flange mounting
Resolution 17-bit (equivalent to 131072 ppr) feedback
Degree of protection IP55
Dimensions (H×W×D) 98.1 mm × 82 mm × 182 mm
Net Height 98.1 mm
Net Width 82 mm
Net Depth 182 mm
Ambient air temperature for operation 0…+40 °C
Ambient air temperature for storage -15…+70 °C
Maximum current 18 A



NEW HCMFS73K Mitsubishi Servo Motor HC-MFS73K Fast shipping 1

Contact: Ms Amy

SKYPE: sandesales01

EMAIL: sales01@sande-elec.com

****Please Contact us for its Availability, due to goods Vary. Thanks much!



These goods are still in stock
