Telemecanique XS4P18AB110 Analog Inductive Sensor

Overview

The XS4P18AB110 is an M18 inductive proximity sensor designed for applications that need analog output rather than a simple switching signal. Its verified product data shows a 0 to 10 V analog output, an 8 mm nominal sensing distance, a non-flush cylindrical M18 design, and a 2 meter cable connection, making it a practical choice for machinery that needs stable metal detection with a usable proportional signal.

This model fits especially well in automation systems where the controller benefits from distance-related analog feedback instead of a single ON/OFF state.

That makes it relevant to positioning support, approach monitoring, fixture confirmation, and other machine tasks where the sensing value itself matters, not only the switching point.

From a hardware standpoint, the sensor combines a compact 41 mm body, PPS front face, PBT enclosure, IP67 protection, and operation from -25 to +70 °C. In day-to-day industrial use, that combination supports reliable performance in machinery exposed to dust, moisture, and regular production cycling.

Key Specifications

Analog Output — Better for Process Feedback

The most important feature of XS4P18AB110 is its 0 to 10 V analog output. That makes it useful in applications where the control system needs a variable signal related to target position or approach distance, rather than just a discrete presence signal.

In practical terms, it opens the door to smoother monitoring logic, analog threshold handling, and more informative feedback inside the control program.

For engineers, this changes the way the sensor is selected. A discrete sensor is often chosen for switching certainty; an analog inductive sensor is usually chosen when the application needs more process awareness.

That makes XS4P18AB110 a stronger fit for controlled positioning and monitoring tasks than for simple binary detection alone.

M18 Form Factor — Compact but Industrial

The M18 cylindrical body and 41 mm overall length make this model easy to integrate into compact machine frames, brackets, and standardized threaded mounting points.

The non-flush design should still be respected during installation, because surrounding metal can affect sensing behavior if the mounting arrangement is too tight.

At the same time, the IP67 rating and industrial temperature range help the sensor fit real factory conditions instead of bench-only applications.

That balance of compact size and robust construction is one reason M18 analog inductive sensors remain useful in automation and retrofit work.

FAQ

Q1: What is the main advantage of the 0-10 V analog output?
It provides a variable output signal instead of a simple switching state. That is useful when the controller needs more detailed information about target approach or position inside the operating zone.

Q2: What kind of applications is XS4P18AB110 suited for?
It is well suited to positioning support, part approach monitoring, fixture confirmation, and compact automation tasks where metal detection must be interpreted more progressively than a standard ON/OFF sensor allows.

Q3: Is this a flush-mount sensor?
No. It is a non-flush M18 sensor, so the mounting arrangement should allow proper clearance around the sensing face to preserve stable operation.

Q4: Is it suitable for factory environments?
Yes. Its published specifications include IP67 protection, PPS front material, PBT enclosure, and an operating range of -25 to +70 °C, which supports normal industrial use.

Q5: What should buyers verify before ordering?
The key checks are the required output type, supply voltage, cable requirement, mounting style, and sensing range. Analog sensors should also be matched to the receiving controller or monitoring circuit, not just to the mechanical size.
