A06B-6114-H209 FANUC AC Servo Amplifier Unit A06B6114H209 A06B-6114-H209

FANUC A06B-6114-H209 Dual-Axis Alpha i Servo Module

Overview

The A06B-6114-H209 is a dual-axis Alpha i servo amplifier module identified in public references as SVM2-80/80i. Replacement-market sources consistently describe it as a FANUC Alpha i two-axis servo module in the A06B-6114 family, which gives it a clear position as a machine-support and replacement component for installed FANUC motion systems.

From a practical engineering standpoint, this model is easier to understand than a mixed-capacity amplifier because both controlled axes belong to the same current class.

Public listings show 19 A rated output on both the L and M axes, along with 283–339 V rated input, 11 kW power context, and 240 V maximum output voltage.

That makes the module a symmetrical dual-axis Alpha i unit intended for applications where both driven axes require the same amplifier class.

Because it is commonly associated with FANUC i Series environments, this module is most valuable when used to preserve an existing cabinet layout and original control compatibility.

In product-page terms, the most useful description is technical and exact: A06B-6114-H209 is a FANUC Alpha i dual-axis servo module, model SVM2-80/80i, for CNC replacement and motion-control support.

Key Specifications

Symmetrical Dual-Axis Structure

One of the strongest practical points about A06B-6114-H209 is that it is a symmetrical dual-axis module. Both axes share the same 19 A rated current class, which gives the product a cleaner technical identity than mixed-capacity dual-axis amplifiers.

In real machine support, that can simplify matching when the original equipment used the same amplifier class on both controlled axes.

That symmetry also gives the page more technical clarity. SVM2-80/80i is not just a label; it helps confirm to maintenance personnel that the module sits in the correct two-axis Alpha i family and is intended for a defined output class on both channels.

FAQ

Q1: What kind of product is A06B-6114-H209?
It is a FANUC Alpha i dual-axis servo amplifier module identified as SVM2-80/80i. In practical machine use, it supports two servo axes inside an installed FANUC motion-control system and is typically sourced for replacement or support work.

Q2: Why is the SVM2-80/80i designation important?
It confirms the model’s exact place in the Alpha i dual-axis servo family and tells the buyer that both axes belong to the same 80/80i current class.

For technical users, that is often the clearest confirmation that the replacement belongs to the correct drive category.

Q3: Are the 19 A / 19 A ratings significant?
Yes. They show that the amplifier is a symmetrical dual-axis model rather than a split-capacity one. In practical replacement work, that distinction helps the buyer avoid confusing it with similar-looking modules from the same broader family.

Q4: Is this module usually used with i Series controls?
Public references commonly associate this model with FANUC i Series control environments.

In practice, that helps frame the likely machine generation and can be useful during compatibility checks in service or retrofit planning.

Q5: What should buyers verify before ordering?
Buyers should confirm the exact part number, the SVM2-80/80i designation, the dual-axis architecture, and the machine’s original control and servo layout.

For FANUC drive modules, correct family identification is usually as important as the order code itself.
