Simatic PLC Programmable Logic Controller DP Interface 6ES7153-2BA82-0XB0

Siemens 6ES7153-2BA82-0XB0 SIMATIC DP Interface Module

Overview

The 6ES7153-2BA82-0XB0 is a SIMATIC DP interface module IM 153-2 HF for ET 200M. Siemens describes it as a connection module for DP/PA-LINK and ET 200M, designed for up to 12 S7-300 modules, with redundancy capability, timestamping suitable for isochronous mode, and operation of 64-channel modules with 32 signals per slot.

It is also identified as a replacement part, which places it directly in the installed-base support path for ET 200M systems.

This interface module sits at the communication core of an ET 200M station. It defines how the distributed station is represented on PROFIBUS DP and how the connected S7-300 I/O modules are integrated into the wider control architecture.

Its published features make it suitable for stations where high channel density, extended temperature operation, timestamping, and redundancy are already part of the system design.

Technical Data

Application Value

This module is well suited to ET 200M distributed I/O stations in process, utility, and plant-control cabinets where the original architecture already depends on PROFIBUS DP, redundancy, and a relatively large station structure.

Its published support for up to 12 S7-300 modules, timestamping, and expanded HART auxiliary-variable handling makes it especially relevant in installations where the communication side of the ET 200M station is not a simple entry point, but a core part of the control design.

In replacement work, this model is important because the interface module determines how the entire ET 200M station presents itself to the network and how the installed module bank is organized. Keeping the same IM 153-2 HF class helps preserve the original station structure, communication profile, and distributed-I/O behavior.

Selection Notes

The key checks are the ET 200M system type, the IM 153-2 HF designation, the requirement for up to 12 S7-300 modules, the need for redundancy, and the use of PROFIBUS DP with the same electrical and environmental profile.

These points define whether the module matches the original station architecture.

FAQ

Q1: What kind of module is 6ES7153-2BA82-0XB0?
It is a SIMATIC DP interface module IM 153-2 HF for ET 200M. Siemens specifies it as the communication-side connection module for an ET 200M station, not as a digital or analog signal module.

It is built to support the distributed-I/O structure behind it, including station communication and module-bank integration.

Q2: Why is the “HF” version important?
The published product designation is IM 153-2 HF, and Siemens associates this version with features such as timestamping suitable for isochronous mode, support for up to 12 modules, and operation with higher-density signal structures.

That makes it more than a basic ET 200M interface entry and places it in the higher-function segment of the IM 153-2 family.

Q3: Why do redundancy and timestamping matter on this model?
Siemens explicitly lists redundancy capability and timestamping for this part. In practical terms, those functions matter in installations where event accuracy, availability, and consistent station behavior are part of the control specification.

They are not generic extras; they are part of the module’s defined hardware role.

Q4: What communication structure does this module use?
This model is a PROFIBUS DP slave interface with a 9-pin Sub-D socket and a maximum transmission rate of 12 Mbit/s. Siemens also lists DP features such as SYNC, FREEZE, and direct data exchange capability, which confirms its role inside established PROFIBUS-based ET 200M stations.

Q5: What should be checked before ordering?
Check the installed part number, confirm the station is ET 200M, verify that the application requires IM 153-2 HF, and make sure the system depends on the same 12-module station size, redundancy, PROFIBUS DP communication profile, and 24 V DC electrical class. Those are the main match points for this model.
