New in box Mitsubishi PLC Module A1SX41 Fast Shipping Good Price

Mitsubishi A1SX41 | MELSEC-A Slim Series 32-Channel 24VDC Sink Digital Input Module — Local I/O / NPN Compatible / A1S Rack / Discontinued Spare

32 Sink Inputs in the MELSEC-A Rack Architecture

The A1SX41 is a 32-channel digital input module in Mitsubishi's MELSEC-A Series — the modular rack-based PLC platform that preceded the MELSEC-Q series as Mitsubishi's mid-to-large automation platform. The "A1S" prefix identifies the slim form factor variant within the A-series family, occupying one slot in the A1S slim rack system.

Thirty-two digital inputs, each accepting 24VDC sink (NPN) signals, collect field device status — limit switches, proximity sensors, photoelectric sensors, pushbuttons, and relay contacts — and pass them to the MELSEC-A CPU via the rack's internal bus. The CPU reads the 32 input states in each scan cycle through the module's input image assignment.

Sink (NPN) input type means the input circuit is activated by a current path to 0V through the field device, rather than current from a 24V source. NPN-output proximity sensors and other NPN-output devices connect directly. PNP-output (sourcing) sensors require signal conversion or interposing relays to work with sink inputs. This wiring convention distinction defines what field devices can connect to the A1SX41 without additional hardware.

The A1SX41 is firmly a maintenance and lifecycle part today. The MELSEC-A series was succeeded by MELSEC-Q in the late 1990s and is long discontinued. For the installed base of MELSEC-A systems still in operation — process plants, factory utilities, legacy machine tools — the A1SX41 is sourced through the A-series aftermarket, not through standard Mitsubishi distribution.

Key Specifications

A1S Slim Series — Where the A1SX41 Fits in the MELSEC-A Family

The MELSEC-A series includes two physical form factors: the full-size A-series rack (A2US, A3U, etc.) and the slim A1S rack. The A1S designation marks the smaller footprint variant — modules are narrower and lighter than full-size A-series modules, designed for smaller cabinets. The A1SX41 is specifically an A1S module and physically fits only in A1S-compatible racks. It is not interchangeable with full-size A-series digital input modules (A1X40, A1X41 in full-size format) — slot geometry differs.

Within the A1S input module family:

• A1SX40: 16 channels, 24VDC sink
• A1SX41: 32 channels, 24VDC sink (this module)
• A1SX80: 32 channels, 5/12VDC TTL-compatible inputs

The A1SX41's 32-channel count makes it the highest-density sink input option in the A1S family — two modules provide 64 input channels in the same rack space that might otherwise require four 16-channel modules.

Application Scenarios

Legacy process control systems: MELSEC-A PLCs in chemical, water treatment, and utility plants remain operational in many facilities. The A1SX41 provides replacement capability when an installed input module fails — matching the original 32-channel NPN configuration without wiring changes.

Machine tool and factory automation: Many machine tools built in the 1990s with MELSEC-A racks remain in production. A failed input module causes immediate shutdown of that machine's digital input sensing. Direct replacement with A1SX41 restores the input map without programme modification.

Rack restoration and maintenance: When an A1S rack needs partial restoration (damaged modules, failed input cards), the A1SX41 provides the specific NPN input configuration the original system requires — not a substitute module type that would require wiring rewiring or programme address modification.

FAQ

Q1: What is the difference between sink (NPN) and source (PNP) input modules, and why does it matter for the A1SX41?

Sink (NPN) input modules are activated by completing a current path to 0V — the field device connects the input terminal to 0V when the sensor is active. Source (PNP) modules are activated by a 24V source at the input. If the A1SX41 is installed in a machine wired with NPN-output sensors, the wiring works directly. Replacing it with a PNP input module would leave all field devices incompatible without rewiring — a significant installation problem in a running machine.

Q2: Is the A1SX41 directly interchangeable with A-series digital input modules in full-size racks?

No. The A1S slim form factor and the full-size A-series form factor use different slot dimensions. An A1SX41 fits only in A1S-format racks. Full-size A-series equivalent digital input modules (A1X40, A1X41 series) fit full-size A racks. Confirm the physical rack format — A1S slim or full-size — before ordering.

Q3: How is the A1SX41 configured for its rack address?

MELSEC-A I/O modules are addressed by their slot position in the rack — the CPU reads each slot's module configuration at startup and assigns input/output addresses based on slot sequence. No DIP switches or software address settings are required for standard local I/O modules. The slot position in the rack defines the input address block (%X assignments in GX Developer or ladder programme).

Q4: What programming software is used for MELSEC-A systems?

GX Developer is the programming software for MELSEC-A (and Q, L, FX series). GX Works2 supports some A-series CPUs in limited capacity. The A-series uses MELSAP ladder and SFC programming. GX Works3 does not support the MELSEC-A series. Programming requires connecting to the A-series CPU's RS-422 programming port using a compatible PC adapter.

Q5: Where is the A1SX41 sourced today?

Through the MELSEC-A spare parts aftermarket — legacy automation dealers, industrial surplus suppliers, and specialist Mitsubishi A-series parts distributors. The MELSEC-A platform is long discontinued; Mitsubishi does not supply A1SX41 through standard distribution channels. Confirm the A1S slim format, 32-channel 24VDC sink specification, and physical condition from the supplier before ordering. Tested units verified in an A1S rack are preferable to unverified new-old-stock for critical production equipment.
