The 1762-L24BWA's 14 digital inputs divide into two functionally different groups, and the distinction matters for how the machine is designed.
10 standard 24VDC inputs: Standard digital inputs filtered for normal sensor signals — pushbuttons, limit switches, proximity sensors, and relay contacts. Response time is in the millisecond range, appropriate for all normal machine sequencing tasks.
4 fast 24VDC inputs: High-speed inputs with significantly shorter response time — designed for signals that switch faster than standard inputs can reliably capture. These fast inputs handle pulse train counting (flow meters, encoder pulses, production counters), short-duration trigger signals, and any input that must be detected within a single PLC scan cycle or between scans. On a machine with a production counter at 200 pulses per minute and a high-speed reject gate trigger, the fast inputs handle what the standard inputs cannot.
This 10+4 split is a design choice, not an accident. Machines that need only standard sensor inputs use the same 14 inputs without the fast input capability serving any purpose. Machines that mix slow sensors with one or two high-speed signals get both types from one controller, without a separate high-speed counter module.
| Parameter | Value |
|---|---|
| Power Supply | 120/240V AC |
| Standard Inputs | 10 × 24V DC |
| Fast Inputs | 4 × 24V DC |
| Total Inputs | 14 |
| Relay Outputs | 10 |
| Memory | 6 KB |
| RS-232C Protocols | DF1, DH-485, Modbus RTU, ASCII |
| Status | Discontinued spare |
The 1762-L24BWA's built-in RS-232C port supports four communication protocols from a single physical connector:
DF1: Allen-Bradley's point-to-point serial protocol for direct communication between MicroLogix and RSLogix 500 programming terminals, or between MicroLogix units in DF1 polling arrangements.
DH-485: Allen-Bradley's multi-drop network linking multiple MicroLogix and SLC controllers on a shared RS-485 bus. The 1762-L24BWA connects to an existing DH-485 network without an additional communication module.
Modbus RTU: The industry-standard Modbus protocol in RTU binary format, allowing the MicroLogix 1200 to communicate with third-party drives, energy meters, remote I/O, and other Modbus-capable devices as either master or slave.
ASCII: Character-mode serial communication for barcode readers, weigh scales, label printers, and other character-stream devices that send or receive plain text data.
This protocol flexibility from one serial port is a practical advantage in real machine installations where the controller may need to connect to a Modbus drive, receive data from a barcode reader, and be accessed by a programming laptop — all from the same RS-232C connector in different configurations.
Compact packaging equipment: Ten standard sensors monitoring film web, product presence, and seal jaw positions. Four fast inputs counting product throughput from high-speed photoelectric sensors. Ten relay outputs controlling film advance motor, sealer, and pneumatic cutter. RS-232C in Modbus RTU talking to the servo drive for jaw positioning.
Conveyor with batch counting: Standard inputs for stop/start pushbuttons and safety limits. Fast inputs counting product pulses from a conveyor encoder. Relay outputs controlling conveyor motor contactors and diverter gates.
Maintenance spare for installed MicroLogix 1200 systems: The MicroLogix 1200 was widely deployed through the 2000s in compact machine panels. A 1762-L24BWA replacement restores the original I/O address map, fast input assignments, and RS-232C protocol configuration without programme modification.
Q1: What is the difference between 1762-L24BWA and 1762-L24BXB?
The 1762-L24BWA has relay (W) outputs and AC (A) power supply. The 1762-L24BXB has transistor (X = DC source) outputs and DC power supply. The input and memory specifications are the same. Choose BWA when the machine uses an AC supply and relay outputs are preferred for load flexibility; choose BXB when a 24VDC supply panel and fast transistor outputs are required.
Q2: What programming software is used for the 1762-L24BWA?
RSLogix 500 (Rockwell's legacy MicroLogix/SLC 500 programming environment) or Studio 5000 Logix Designer 500 (the current package that includes RSLogix 500 capability). Connection is via the RS-232C serial port with a 1761-CBL-PM02 or equivalent programming cable, or via USB with a 1747-UIC USB-to-DH-485 adapter if the DH-485 protocol is used.
Q3: Can the fast inputs count encoder pulses for position measurement?
The fast inputs can accumulate high-speed pulse counts from single-channel encoders or sensors. The MicroLogix 1200 uses the HSC (High Speed Counter) instruction to manage the fast input count values in the programme. For quadrature (A/B phase) encoder counting with direction detection, verify the specific MicroLogix 1200 HSC configuration from the MicroLogix 1200 reference manual — not all models support full quadrature input from the fast input channels.
Q4: Can additional I/O be added to the 1762-L24BWA?
Yes. The MicroLogix 1200 supports expansion I/O modules (1762-series) connected via the right-side expansion port. Available types include digital input, digital output (relay and transistor), analogue I/O, and RTD/thermocouple input modules. The maximum expansion depends on the power budget of the base controller.
![]()
