Omron CPM1A-40CDR-A-V1 | CPM1A Compact Micro PLC — 24 DI / 16 Relay Outputs / 100–240VAC / RS-232C / 3 Expansion Units / Obsolete Spare

Where the CPM1A Sits — Simpler and Smaller Than the CPM2A

The CPM1A is Omron's earlier generation compact micro-PLC, pre-dating the CPM2A in the same product family lineage. Both are AC-powered, relay-output compact controllers that mount on DIN rail without a rack. What separates them is programme size and built-in capability.

The CPM1A-40CDR-A-V1's programme memory is 1,024 words — roughly equivalent to 1,024 ladder rungs. For straightforward machine sequences: a conveyor with 12 sensors and 8 outputs, a simple packaging station with cycle control and alarm outputs, a utility pump station with level and pressure interlocks. Applications that stay within this scope are the CPM1A's natural territory.

The CPM2A-60CDR-A (also in this product set) provides 4,096 programme steps and 60 I/O points — four times the programme capacity in a physically similar housing. For machines that started on a CPM1A and grew beyond 1,024 steps, a CPM2A replaced it. For machines that still run comfortably within the CPM1A's envelope, the controller does its job without the larger model's added cost.

The -A-V1 suffix identifies the AC supply (A) version at hardware revision V1. The V1 revision is a later production update to the base CPM1A-40CDR-A; it is electrically and functionally compatible with the original in the same cabinet installation.

Key Specifications

CPM1A vs CPM2A — Two Generations, Different Scales

For a machine that was built on the CPM1A and needs a replacement CPU, the CPM1A-40CDR-A-V1 is the correct like-for-like replacement. The CPM2A-60CDR-A cannot directly substitute — its programme structure and memory addressing differ, requiring programme verification before use.

Expansion — What Three Units Provide

CPM1A expansion units connect to the right side of the CPU base unit. Available types: 20-point digital I/O (CPM1A-20EDT or 20EDR), 4-channel analogue input (CPM1A-4AD), 2-channel analogue output (CPM1A-2DA), and temperature sensor input units. Three expansion units bring the maximum system I/O to 100 total points — expanding a 40-point base to cover larger machines that outgrow the base unit's I/O without requiring a larger CPU.

Application Scenarios

Small machine tools and presses: 24 inputs monitor limit switches, interlocks, and tool presence sensors. 16 relay outputs control the press solenoid, clamp cylinders, and alarm indicators. Programme fits within 1,024 steps for a sequential cycle with fault detection.

Pump and fan control: Level switches, pressure sensors, and motor status contacts on inputs; motor contactors and indicator lamps on relay outputs. Simple ladder logic with timers and counters.

Legacy equipment spare: The CPM1A was Omron's standard micro-PLC throughout the 1990s. Many machines built in this era still operate on CPM1A hardware. A CPM1A-40CDR-A-V1 replacement restores the original controller without programme modification.

FAQ

Q1: What is the difference between CPM1A-40CDR-A and CPM1A-40CDR-A-V1?

The -V1 suffix denotes hardware revision 1 — a production update to the base CPM1A-40CDR-A incorporating component changes. Both have identical electrical specifications: 24 DC inputs, 16 relay outputs, 100–240VAC supply, 1,024-word programme, RS-232C port. The -V1 is functionally interchangeable with the original in any installed CPM1A-40CDR-A application.

Q2: What programming software is required?

CX-Programmer (part of the CX-One suite), which connects via the built-in RS-232C peripheral port. The CPM1A is not supported by Sysmac Studio. CX-Programmer V9.x and later include CPM1A device definitions. A USB-to-RS-232 adapter and a CS1W-CN226 or equivalent programming cable connect the PC to the CPU's peripheral port.

Q3: Can the CPM1A-40CDR-A-V1 programme be transferred directly to a CPM2A?

Not without verification. While CX-Programmer can open CPM1A programmes and retarget them to CPM2A hardware, differences in I/O addressing, timer and counter range, and instruction set mean the transferred programme must be tested before commissioning. A CPM1A programme that addresses I/O within the CPM1A's memory map should work on a CPM2A with the same I/O count, but always verify before returning to production.

Q4: Can analogue I/O be added to the CPM1A-40CDR-A-V1?

Yes. The CPM1A-4AD analogue input expansion unit provides 4 channels of 0–10V or 4–20mA input, and the CPM1A-2DA provides 2 analogue output channels. These expansion units count toward the 3-unit maximum. The analogue data is accessed through special data area addresses in the CPM1A programme.

Q5: Where is the CPM1A-40CDR-A-V1 sourced?

Through the Omron CPM1A legacy aftermarket — specialist legacy PLC dealers and tested surplus suppliers. Omron does not produce the CPM1A through current distribution channels. Confirm the -A (AC supply) and -V1 revision from the installed unit's label. Supply of tested units is limited compared to later Omron platforms; building a small spare stock is advisable for facilities with multiple CPM1A installations.
