PLC CPM2A-40CDR-A CPM2A40CDRA CPM2A-4OCDR-A
  • PLC CPM2A-40CDR-A CPM2A40CDRA CPM2A-4OCDR-A
PLC CPM2A-40CDR-A CPM2A40CDRA CPM2A-4OCDR-A

PLC CPM2A-40CDR-A CPM2A40CDRA CPM2A-4OCDR-A

Place of Origin japan
Brand Name OMRON
Certification CE ROHS
Model Number CPM2A-40CDR-A
Product Details
Condition:
New Factory Seal(NFS)
Item No.:
CPM2A-40CDR-A
Origin:
Japan
Highlight:

plc fuji temperature controller

Payment & Shipping Terms
Minimum Order Quantity
1 pcs
Packaging Details
original packing
Delivery Time
0-3 days
Payment Terms
T/T,PayPal,Western Union
Supply Ability
100 pcs/day
Product Description
Omron CPM2A-40CDR-A Programmable Controller
The Omron CPM2A-40CDR-A is a compact Sysmac micro programmable controller built for small machine control and panel applications. This reliable CPM2A series controller combines proven performance with a practical 40-point I/O structure, making it ideal for equipment requiring dependable switching and straightforward PLC control.
Controller Overview
This AC power version operates on 100 to 240 VAC, 50/60 Hz with an AC operating range of 85 to 264 VAC. Built-in communications include an RS-232C port and peripheral port for simplified programming, maintenance, and serial device connectivity in existing control systems.
Key Features
  • 40 I/O configuration with 24 DC inputs and 16 relay outputs
  • 100-240 VAC, 50/60 Hz power supply for the AC model
  • Built-in RS-232C port plus peripheral port for communication and setup
  • Ladder diagram programming with 4,096-word program capacity
  • Expandable design with support for up to 3 units and 100 I/O points maximum
  • Battery-backed clock function and interrupt features for flexible machine control
Technical Specifications
Specification Details
Manufacturer Omron
Series CPM2A
Model CPM2A40CDRA / CPM2A-40CDR-A
Product Type Micro Programmable Controller / Compact PLC
Total I/O Points 40
Inputs 24 DC inputs
Outputs 16 relay outputs
Power Supply 100 to 240 VAC, 50/60 Hz
Operating Voltage Range 85 to 264 VAC
Control Method Stored program method
Programming Language Ladder diagram
Program Capacity 4,096 words
Built-in Ports RS-232C port and peripheral port
Expansion Capacity Up to 3 expansion units
Maximum I/O with Expansion 100 points maximum for 40-point CPU
Clock Function Yes, battery-backed
Ambient Operating Temperature 0°C to 55°C
Dimensions Approx. 150 × 90 × 90 mm
Weight 800 g maximum
Frequently Asked Questions
What is the Omron CPM2A40CDRA?
The Omron CPM2A40CDRA is a CPM2A series micro programmable controller. It is a 40 I/O compact PLC designed for machine and equipment control.
How many inputs and outputs does the CPM2A40CDRA have?
This model has 24 DC inputs and 16 relay outputs, for a total of 40 I/O points.
What power supply does the CPM2A40CDRA use?
The AC version is rated for 100 to 240 VAC, 50/60 Hz. Its operating voltage range is 85 to 264 VAC.
Does this PLC have relay outputs?
Yes. The CPM2A40CDRA is the relay output version of the 40-point AC CPU, with 16 relay outputs.
Does the CPM2A40CDRA support serial communication?
Yes. It includes a built-in RS-232C port, and the CPU also provides a peripheral port.
Can the Omron CPM2A40CDRA be expanded?
Yes. The 40-point CPU can connect up to 3 expansion units, and the maximum I/O capacity can reach 100 points with expansion I/O.
What programming language does this PLC use?
The controller supports ladder diagram programming and uses the stored program method.
What are the dimensions of the CPM2A40CDRA?
The 40-point AC CPU format is approximately 150 mm wide, 90 mm high, and 90 mm deep.
